Entron iPAK2

Section 10 Multiweldin
g
50
Multiwelding (extended feature)
iPAK2 allows up to four transformers to be directly connected or up to eight when used with a decoder.
Up to 8 electrodes can be assigned
to the welding transformers
The electrode number is determined by the weld program:
Parameter Units Range Description
Electrode 0 - 7 The electrode number
The weld programs can be linked together.
The electrode is assigned to a transformer:
Parameter Units Range Description
Electrode 0 - 7 The electrode number
Transformer 0 - 7 The transformer that the electrode is connected to
