Entron iPAK2

Section 9 Histor
y
lo
g
49
History log
iPAK2 stores the results of the last 6000 spot welds in a history log. Each record contains the following
information:
Parameter Units Range Description
Time and date The time and date when the entry was recorded
Program 0 - 255 The weld program used
Pre-current kA 0 – 500 The current recorded during the Pre-heat interval
Main current k
A
0
–
500 The current recorded during the Main heat interval
Post-current k
A
0
–
500 The current recorded during the Post-heat interval
Force kN/lbf Variable The force recorded during the weld
The log can be viewed or reset as required.
