Entron iPAK2

Section 1 Introduction 6
Features
NetFlash programming

WSP3 programming

Ethernet
1

RS232

RS485

MODBUS TCP/IP

MODBUS RTU

Analogue inputs
2
2
Analogue outputs
2
1
Discrete inputs 16
Discrete outputs
3
16
Weld programmes 256
Pre-heat

Main heat

Post-heat
5

Slope

Constant current

Cascade/Mux
5
8
Multi air valve
4, 5
8
Aux valves 7
Force profile
5

Electrodes 8
Real-time clock

Data log (spot welds) 6000
Expansion

Analog control mode
5

1
Two ports
2
0 to 10 V
3
24 V dc, short-circuit proof, monitored
4
Guided contact safety relay, monitored
5
Extended feature
The extended features can be enabled for greater flexibility or more demanding applications.
