Entron iPAK2

Section 13 Pro
g
rammin
g
72
Keypad
Return to the previous screen or move
between menu screens.
Select a different function or parameter.
The selected function or parameter will
flash and the visible window will scroll if
required.
Access the selected function.
Alter the selected parameter. Press both
keys together to set the parameter to 0 or
to its minimum value.
Diagnostic screen
Status
Ready
Measured Pre-current
|‐‐0Aprog7
Program used
Measured Main current
‐|‐11.7kA5.66kN
Measured force
Measured Post-current
‐‐ |  0A ~30.5%
Measured pulse-width
If more than one status message is present they are shown sequentially.
