Entron iPAK2

Section 13 Pro
g
rammin
g
80
Configuration parameters
Variable Channel Address offset Type Description
Configuration %IW0 WORD ARRAY [0..63]
Weld type Configuration[0] %IW0 WORD 0 = spot
1 = seam
2 = analog
Second stage Configuration[1] %IW1 WORD
Bit 0
Bit 1
%IX1.0
%IX1.1
BOOL
BOOL
00 = none
01 = before Squeeze
10 = after Squeeze
Bit 2 %IX1.2 BOOL Reserved
Bit 3 %IX1.3 BOOL 0 = check first program
1 = check every program
Retract Configuration[2] %IW2 WORD 0 = simple
1 = hilift plus
2 = hilift minus
3 = maintained
Measure Configuration[3] %IW3 WORD 0 = primary
1 = secondary
Ip limit Configuration[4] %IW4 WORD 0 – inverter specific
Units Configuration[5] %IW5 WORD 0 = metric
1 = imperial
Electrodes Configuration[6] %IW6 WORD 0 = single, 1 = multi
Fault Configuration[7] %IW7 WORD
Stop Bit 0 %IX7.0 BOOL 1 = stop on fault
EOS Bit 1 %IX7.1 BOOL 1 = EOS on fault
Headlock Bit 2 %IX7.2 BOOL 1 = headlock on fault
iPAK (v1) Bit 3 %IX7.3 BOOL 1 = use Not Ready sense
Contactor Configuration[8] %IW8 WORD 1 - 99 seconds. 0 = off
Program select Configuration[9] %IW9 WORD 0 = external, 1 = internal
Internal prog Configuration[10] %IW10 WORD 0 - 255
I/O source Configuration[11] %IW11 WORD 0 = discrete
1 = MODBUS COM0
2 = MODBUS COM1
3 = MODBUS COM2
4 = RS232 COM3
Regulation Configuration[12] %IW12 WORD 0 = primary
1 = secondary
COM2 address Configuration[13] %IW13 WORD 1 - 247
COM2 baud
code
Configuration[14] %IW14 WORD 0 = 9600
1 = 19200
2 = 38400
3 = 57600
Bus monitor Configuration[15] %IW15 WORD 0 = iPAK (v1) inverter
1 = iPAK2 inverter
Adapter code Configuration[16] %IW16 WORD
Analog output
function
Configuration[17] %IW17 WORD 0 = force
1 = waveform
Analog output
scale (10 V =)
Configuration[18] %IW18 DWORD 0 – 500 kA
Security Configuration[20] %IW20 WORD 0 = off
1 = key-switch
2 = PIN on WSP3
Security timeout Configuration[21] %IW21 WORD 0 – 10 minutes
Security PIN0 Configuration[22] %IW22 WORD 1000 - 9999
Security PIN1 Configuration[23] %IW23 WORD 1000 - 9999
Security PIN2 Configuration[24] %IW24 WORD 1000 - 9999
Security PIN3 Configuration[25] %IW25 WORD 1000 - 9999
Security PIN4 Configuration[26] %IW26 WORD 1000 - 9999
Reserved Configuration[27]-[38]
Features Configuration[39] %IW39 WORD 0 = standard
1 = extended
Toroid test Configuration[40] %IW40 WORD 0 = Off, 1 = On
Reserved Configuration[41]-[63]
