5
WARNING:
Operation of this heater when not connected to a properly installed and maintained venting system can result in
carbon monoxide (CO) poisoning and possible death.
Specifications
DIMENSIONS:
Floor to center of ue REAR VENT
23” (59.7 cm)
CLEARANCES TO COMBUSTIBLES:
A. Sidewall to unit 11 inches (27.9 cm)
B. Backwall to unit 2.5 inches (6.35 cm)
C. Corner to unit 2.5 inches (6.35 cm)
D. Cieling 60 inches above oor (152.4 cm)
E. Floor (hard wood and linoleum) 0 inches
Note: Carpeted surfaces must use a non combustible hearth pad.
Minimum Alcove Dimensions:
Width 48 inches (121.9 cm)
Depth 24 inches (60.96 cm)
Height 60 inches (152.4 cm)
CLEARANCES MUST BE SUFFICIENT TO ALLOW ACCESS FOR MAINTENANCE AND SERVICE
Figure 1: Westport Exterior Dimensions.
Figure 2: Clearances to combustibles.
