32
Routine Maintenance and Service
Periodically check to ensure that your system is clean.
Periodically check the pilot and burner. Check to see that all the burner ports are clean and clear. Check the pilot
head for blockage. Check to ensure the pilot ame is blue with no or very small yellow tips.
OPENING THE DOOR
Turn unit off and wait until the appliance has cooled down.
Remove the unit top from the unit by lifting straight up.
Lift the two door handles located on either side of the door and
lift the glass door assembly straight up and out (see Figure 57
and 58).
Carefully open the two cast doors or remove if necessary.
Ensure the door is properly fastened after cleaning before
attempting to re-light the appliance.
CLEANING THE GLASS
Allow the glass to cool before cleaning.
It will be necessary to clean the ceramic glass periodically. During
a cold start up, condensation will sometimes form on the glass.
This is a normal condition with all gas replaces and stoves.
However, this condensation can allow dust and lint to cling to
the glass surface. Initial paint curing of the appliance can leave
behind a slight lm on the glass. This is a temporary problem. It
is therefore recommended that the glass be cleaned initially after
about the rst two weeks of use.
Depending upon the amount of use, cleaning should be required
no more than two or three times per season.
To clean the door, use a mild glass cleaner and a soft cloth.
Abrasive cleaners will damage the glass and gold surfaces.
TO REPLACE DOOR
The glass in this appliance is ceramic. If the glass is damaged or
broken a factory door with glass replacement must be used.
• Open door following above instructions.
• Door with glass must be purchased from an ENVIRO dealer (part
#: 50-463). Do not use a substitute materials; it will void
the warranty.
Figure 57: Handles for Removing Door.
Figure 58: Removing of Door.
