AlcoQuant® 6020 – Breathalyser – Operating Instructions
12
1212
12 Technical Specifications
Technical SpecificationsTechnical Specifications
Technical Specifications
Device:
Device:Device:
Device:
Measuring modes:
Measuring range:
Accuracy:
Max. Measuring error, in relation to the ethanol
standard:
Range 0 to 1‰
Range 1 to 2‰
Range > 2‰
Standard deviation:
Ambient conditions:
Temperature range – operation:
Temperature range – storage:
Optimum storage temperature (sensor):
Ambient pressure:
Ambient humidity:
Minimum expiration volume:
Batteries:
Number of measurements per battery pack:
Device interface:
Dimensions ( L x W x H):
Weight:
Active and passive
0 to 5.5 ‰ BAC
± 0.05 ‰ absolute
± 5 % of measured value
± 10 % of measured value
0,008‰
-5°C to +50°C / +23F to +122F
-20°C to +60°C / -4F to +140F
0°C to +25°C / +32F to +77F
600 to 1400 hPa
20 to 98 % r.h.
1.2 litres or depending on requirement
4 x R6 (AA) Mignon cells
more than 1600 tests, depending on the batteries and the
ambient conditions
RS 232 (serial interface). Data can be transferred to a PC or
printer.
190 mm x 61 mm x 38 mm
275 g incl. Batteries
Miscellaneous:
Miscellaneous:Miscellaneous:
Miscellaneous:
Ready to measure after switching on:
Ready to measure after 0 ‰ measurement:
Ready to measure after 1 ‰ measurement:
Sensor type:
Cross sensitivities:
Mouthpiece holder:
Mouthpieces:
Units:
approx. 6 sec.
approx. 2 sec.
approx. 5 sec.
E100 electrochemical measuring cell
In the form of other substances accompanying respiration,
such as acetone, CO etc., these are negligible.
Depends on mouthpiece (type S or D)
Disposable mouthpiece
0Standard: mg/L, ‰ ;User-configurable on request: %,
µg/100ml, µg/L, g/100ml, mg/100ml, PAF, PAWF, all units
used worldwide and modes according to requirements
