Arrow Series Technical Reference Manual
5
#4-40 Mounting Inserts (2x)
1.2.2.1 Arrow Overview
Mini USB Receptacle
(Type B)
Smart Battery Pack
Antenna Connector
(SMA Female)
DC Charging Jack
1.7mm Positive Center Pin
(9 to 16 VDC Max)
Main
LED Interface
Battery
Thumb Screw
Battery
LED
Interface
