Arrow Series Technical Reference Manual
2
1.1.2 Arrow 100 GNSS - GIS Package
1. Arrow receiver with Arrow Smart Battery Pack
2. Single-Frequency GNSS / LBand Precision Antenna (304)
with removable magnets
3. Two-section Antenna Cable
4. Spare Antenna Cable
5. Softhat for Antenna
6. Nylon Carrying Case (belt-clip & shoulder strap)
7. 12V International Power Supply for Arrow Smart Battery
8. USB Data Cable
Figure 1-2 : Arrow 100 GNSS - GIS Package Content
1.1.3 Arrow 200 GNSS – High-Accuracy GIS Package
1. Arrow 200 receiver with Arrow Smart Battery Pack
2. Dual-Frequency GNSS / LBand Precision Antenna (504) with
removable magnets
3. Large Antenna Mounting Plate
4. Two-section Short Antenna Cable for survey pole
5. Spare Antenna Cable
6. Arrow Pole Mount Bracket
7. Range Pole Clamp
8. USB Data Cable
9. 12V International Power Supply for Arrow Smart Battery pack
10. Hard Shell Case
Figure 1-3: Arrow 200 GNSS – High-Accuracy GIS Package
