Arrow Series Technical Reference Manual
1
1. GETTING ACQUAINTED WITH YOUR ARROW
This chapter describes the accessories included with the Arrow receiver kits and the various optional
accessories available through your dealer.
If you are new to GPS/GNSS, SBAS, RTK or Atlas
TM
LBand services, we recommend that you browse
our website for further information on these services and technologies.
1.1 UNPACKING YOUR ARROW RECEIVER
If you find that any of these items listed below are damaged due to shipment, please contact the
freight carrier immediately for assistance.
When you unpack your Arrow receiver, please ensure that it is complete by comparing the parts
received against the packing slip. There are two types of packages available: Standard GIS package
for the Arrow Lite GPS and Arrow 100 GNSS and the High-Accuracy GIS package for the Arrow 200
GNSS. GIS and Survey accessories and kits are available for any of the three models.
Unless your system has been equipped differently than a Standard or High-Accuracy GIS Package,
the following parts should be included:
1.1.1 Arrow Lite GPS - GIS Package
1. Arrow receiver with Arrow Smart Battery Pack
2. L1 GPS Precision Antenna (029) with removable magnets
3. Two-section Antenna Cable
4. Spare Antenna Cable
5. Softhat for Antenna
6. Nylon Carrying Case (belt clip & shoulder strap)
7. 12V International Power Supply for Arrow Smart Battery
8. USB Data Cable
Figure 1-1 : Arrow Lite GPS - GIS Package Content
Note – If you find any discrepancy between your packing slip and the content of your shipment, please
contact your reseller immediately.
