Assembly
Installation location
When selecting the position for the flake ice
machine, please not the following:
• The ake ice machine may only be placed
indoors.
• Verify that the ambient temperature of the
system is between +10°C and +40°C.
• The ake ice machine may not stand next to
sources of heat.
• Avoid direct sunlight.
Unpacking the machine
The ake ice machine is delivered on a wooden
pallet wrapped in lm.
• Remove the packaging. Ensure that the ma-
chine is not damaged when using sharp-
edged tools.
E-Cool Wall B
Art. No. 94 6096
E-Cool Wall S
Art. No. 94 6087
Fig. 3
Fig. 4
Flake ice machine
Insulating hose -20015614-
HT elbow 45° DN 75 -20015884-
HT pipe DN 75 1 -20015642-
Reducer 87/75 -20015644-
Stainless steel pipe -198750-
Flake ice machine
Ice duct connection -198770-
Reducer 87/75 -20015644-
Stainless steel pipe -198750-
Cover -198700-
