EP Equipment CQD15S-E - Page 13

6
h
7
Seat height/standing height
13.2
in.
h
8
Height of wheel arms
11
in.
l
1
Overall length
See Form 4
in.
l
2
Length to face of forks
See Form 4
in.
b
1
/ b
2
Overall width
42.5/43
in.
s/e/l
Fork dimensions
1.6×4×42
in.
b
3
Fork Frame width
32.6
in.
b
5
Distance between fork-arms
7.9-24.4
in.
b
4
Distance between wheel arms/loading
surfaces
29.5
in.
α/β
Tilt of mast/fork carriage forward/backward
2/4
°
l
4
Reach distance
See Form 4
in.
m
1
Ground clearance, laden, below mast
2.75
in.
m
2
The minimum ground clearance of frame
2.75
in.
Ast
Aisle width
1
）
, 1000×1200 pallet crossways
See Form 4
in.
Ast
Aisle width
1
）
, 800×1200 pallet lengthways
See Form 4
in.
Wa
Outer turning radius
69.5
in.
l
7
Length across wheel arms
（
exclusive fork
）
75.3
in.
Tyre type
PU/PU
Tyre size, driving wheels
10.2×4.1
in.
Tyre size, loading wheels
10×4.5
in.
Tyre size, caster wheels
7×2.8
in.
Wheels, number driving
，
caster/loading
(x=drive wheels)
1
，
2
，
2
b
10
Track width, front,driving side
27.5
20.5
in.
b
11
Track width,rear,loading side
38.3
in.
1） Including safety distance a = 200 mm
2） Sound pressure level at the driver’s ear 75 dB(A)
