1.3 Standard Version Specifications
Technical specification details in accordance with VDI2198. Technical modifications
and additions reserved.
1.3.1 Performance data for standard Reach Trucks
Item
Description
CQD15S
CQD15S-E
Unit
Drive unit
Battery
Operator type
Standing
Q
Load capacity
3307
lb.
c
Load center
23.6
in.
Travel speed, laden/ unladen
5.2/5.6
mph
Lifting speed, laden/ unladen
51.2/88.6
fpm
Lowering speed, laden/ unladen
88.6/84.6
fpm
Reaching speed, laden / unladen
163.3
fpm
Maximum gradeability, laden/ unladen
8/10
％
Service weight (With battery)
See Form 3
lb.
Loadin
g
Unladen, Front / Rear, fork advanced
2709/2711
2184/2711
lb.
Unladen, Front / Rear, fork retracted
3573/1865
3062/1880
lb.
Laden, Front / Rear, fork advanced
1080/7595
573/7592
lb.
Laden, Front / Rear, fork retracted
3329/5326
2828/5326
lb.
Drive motor rating S2 60 min.
5.3
kW
Lift motor rating at S3 15%
11
kW
Battery voltage/ rated capacity (5h)
See Form 2
V/Ah
Battery weight
See Form 2
lb.
1.3.2 Dimensions
Item
Description
CQD15S
CQD15S-E
Unit
y
Wheelbase
59.2
58.6
in.
h
1
Height, mast lowered
See Form 1
in.
h
2
Free lift
See Form 1
in.
h
3
Lift height
See Form 1
in.
h
4
Height, mast extended
See Form 1
in.
h
6
Height of overhead guard (cabin)
88
in.
