Item
Control / Display
Function
1
Hydraulic control handle
Function operation:
• Load handler lift/lower
• Mast support extend / retract
• Fork forward or backward tilt
• Sideshift left / right
2
Travel switch
Select the required driving direction.
3
Emergency brake switch
Disconnects the supply current, deactivates all electrical
functions, causing the truck to brake automatically.
4
Foam Pad
For the driver rely on.
5
"Horn" button
Activates the horn.
6
Cushion
For the driver rely on.
7
Drive pedal
• Not applied: Travel inhibited, truck decelerates.
• Applied: Travel released.
8
Lock
Close the backdoor
9
Steering wheel
Steers the truck in the required direction.
10
Display unit
Operating information and warning message display.
11
Light switch (optional)
Switch on or off the light.
12
Key switch
Switches control current on and off. Removing the key prevents
the truck from being switched on by unauthorised personnel.
