17
Item
IP1000-12
IP1000-22
IP1000-11
IP1000-21
Rated Input Voltage
12VDC
24VDC
12VDC
24VDC
Input Voltage Range
10.8～16VDC
21.6～32VDC
10.8～16VDC
21.6～32VDC
Input Surge Voltage
＜20VDC
＜40VDC
＜20VDC
＜44VDC
Output Voltage
220VAC/230VAC (±5%)
110VAC/120VAC(±3%)
Output Frequency
50/60±0.1Hz
Output Continuous
Power
800W
Output Power 15 min.
1000W
Surge power
1600W
Power factor
0.2-1(VA lower than output continuous power)
Output Wave
Pure sine wave
Distortion THD
THD≤3%
①
THD≤5%
①
Max. Efficiency
94.5%
92.5%
No-load Current
＜0.8A
＜0.5A
＜0.8A
＜0.5A
USB Output Port
②
5VDC/Max.1A
RS485 Com. Port
②
5VDC/200mA
Binding Post
Φ10mm
Overall Dimension
298.3×231.5×98.5mm
284.7×231.5×98.5mm
298.3×231.5×98.5mm
284.7×231.5×98.5mm
Mounting Dimension
183×220mm
163×219.5mm
183×220mm
163×219.5mm
Mounting Hole Size
Φ5.5mm
Net Weight
3.9kg
3.6kg
3.9kg
3.6kg
①Test condition: Rated Input Voltage, Output Continuous Power, Resistive load.
②Conventional products don’t have this port; the port is optional.
