Epever IP350-12 - Page 22

19
IP2000-22
IP2000-42
IP2000-21
IP2000-41
Rated Input Voltage
24VDC
48VDC
24VDC
48VDC
Input Voltage Range
21.6～32VDC
43.2～60VDC
21.6～32VDC
43.2～60VDC
Input Surge Voltage
＜40VDC
＜80VDC
＜40VDC
＜80VDC
Output Voltage
220VAC(±5%)
230VAC(-10%～+5%)
110VAC(±5%)
120VAC(-10%～+5%)
Output Frequency
50/60±0.1Hz
Output Continuous
Power
1600W
Output Power 15 min.
2000W
surge Power
3200W
Power factor
0.2-1(VA lower than output continuous power)
Output Wave
Pure sine wave
Distortion THD
THD≤3%
①
THD≤5%
①
Max. Efficiency
95%
94%
No-load Current
＜0.6A
＜0.4A
＜0.6A
＜0.4A
USB Output Port
②
5VDC/Max.1A
RS485 Com. Port
②
5VDC/200mA
Binding Post
Φ10mm
Overall Dimension
326.12×231.5×98.5mm
Mounting Dimension
208×219.5mm
Mounting Hole Size
Φ5.5mm
Net Weight
4.6kg
①Test condition: Rated Input Voltage, Output Continuous Power, Resistive load.
②Conventional products don’t have this port; the port is optional.
