Epever SolarV TRIRON Series User Manual

Copyright© 2022 SolarV GmbH All rights reserved.
21
ʒ Load type
Operating:
Step1: Press the button to switch to the load type interface, and long-press the
button until the load type flashes.
Step2: Press the button to select the load type.
Step3: Press the button to confirm.
NOTE: Please refer to 5.2 for the load working modes.
4.1.3 Display Standard 2 (DS2)
δ
δ
1ε
ε
Indicator
Indicator
Color
Status
Instruction
Green On Solid
PV charges the battery with a low
current
Green OFF
1. No sunlight
2. Connection Error
3. Low PV voltage
Green Slowly Flashing(1Hz) Normal charging
Green Fast Flashing(4Hz) PV Over voltage
Green On Solid Normal
Green
Slowly Flashing(1Hz)
Full
Green
Fast Flashing(4Hz)
Overvoltage
Orange
On Solid
Under voltage
Red On Solid Over discharged
Red Slowly Flashing(1Hz)
Battery Overheating
Low temperature
ķ
ķ
