Epever UPower Series User Manual

5
UP1500-M3222
10mm
2
/8AWG
2P—63A
UP2000-M3322
10mm
2
/8AWG
2P—63A
UP3000-M3322
10mm
2
/8AWG
2P—63A
UP3000-M6322
16mm
2
/5AWG
2P—100A
UP3000-M2142
6mm
2
/10AWG
2P—32A
UP3000-M6142
16mm
2
/5AWG
2P—100A
UP5000-M6342
16mm
2
/5AWG
2P—100A
UP5000-M8342
25mm
2
/4AWG
2P—125A
UP5000-M10342
25mm
2
/4AWG
2P—125A
NOTE: When the PV modules connect in series, the open circuit voltage of the PV array must not
exceed max. PV input voltage at 25℃ environment temperature.
 Recommended wire of Utility
Model
Utility wire size
UP1000-M3212
2.5mm
2
/14AWG
UP1000-M3222
2.5mm
2
/14AWG
UP1500-M3222
2.5mm
2
/14AWG
UP2000-M3322
4mm
2
/12AWG
UP3000-M3322
6mm
2
/10AWG
UP3000-M6322
6mm
2
/10AWG
UP3000-M2142
6mm
2
/10AWG
UP3000-M6142
6mm
2
/10AWG
UP5000-M6342
10mm
2
/8AWG
UP5000-M8342
10mm
2
/8AWG
UP5000-M10342
10mm
2
/8AWG
NOTE: The utility input has the circuit breaker already and there is no need to add any more.
 Recommended wire and circuit breaker of battery
Model
Battery wire size
Breaker
UP1000-M3212
16mm
2
/6AWG
2P—100A
UP1000-M3222
16mm
2
/6AWG
2P—100A
UP1500-M3222
16mm
2
/6AWG
2P—100A
UP2000-M3322
25mm
2
/4AWG
2P—125A
UP3000-M3322
35mm
2
/2AWG
2P—200A
UP3000-M6322
35mm
2
/2AWG
2P—200A
UP3000-M2142
16mm
2
/6AWG
2P—100A
UP3000-M6142
16mm
2
/6AWG
2P—100A
UP5000-M6342
35mm
2
/2AWG
2P—200A
UP5000-M8342
35mm
2
/2AWG
2P—200A
UP5000-M10342
35mm
2
/2AWG
2P—200A
NOTE: Type of circuit breaker is selected based on non-independent connection of inverter at the
battery end where there is no anther inverter connected.
