Environmental Parameters
Item
XTRA
1206N
XTRA
2206N
XTRA
1210N
XTRA
2210N
XTRA
3210N
XTRA
4210N
XTRA
3215N
XTRA
4215N
XTRA
3415N
XTRA
4415N
Environment temperature
◆
(100%
input and output)
-25℃~+50℃(LCD)
-30℃~+50℃(No LCD)
-25℃~+45℃(LCD)
-30℃~+45℃(No LCD)
Storage temperature range
-20℃~+70℃
Relative humidity
≤95%, N.C.
Enclosure
IP33
★
Pollution degree
PD2
◆The controller can full load working in the working environment temperature, When the internal temperature reach to 81℃, the reducing charging power
mode is turned on. Refer to P34.
★3-protection against solid objects: protected against solids objects over 2.5mm.
3-protected against sprays to 60°from the vertical.
Mechanical Parameters
Item
XTRA1206N
XTRA1210N
XTRA2206N
XTRA2210N
XTRA3210N
XTRA3215N
XTRA4210N
XTRA3415N
XTRA4215N
XTRA4415N
Dimension
175×143×48mm
217×158×56.5mm
230×165×63mm
255×185×67.8mm
255×187×75.7mm
255×189×83.2mm
Mounting
dimension
120×134mm
160×149mm
173×156mm
200×176mm
200×178mm
200×180mm
Mounting hole
size
Φ5mm
Terminal
12AWG(4mm
2
)
6AWG(16mm
2
)
6AWG(16mm
2
)
6AWG(16mm
2
)
6AWG(16mm
2
)
6AWG(16mm
2
)
Recommended
12AWG(4mm
2
)
10AWG(6mm
2
)
8AWG(10mm
2
)
8AWG(10mm
2
)
8AWG(10mm
2
)
6AWG(16mm
2
)
