19
RFRP
V2
Room Thermostat CP4
V2
LCD Symbol Description
Operating mode
Current program
Day / Month
Day of the week
Room Temperature
Battery low symbol
Wireless symbol
Heating on symbol
Keypad lock symbol
Current Time
(Boost to time)
Frost symbol
Target Temperature
