Ref� No� Product No� Qty Description Specification
1 87003793 1 Mounting rail
2 87003679 1 Bracket
3 87003678 1 Fork bridge
4 87001087 1 Electric button
For lifting arm
5 87001509 2 Light diode 24V
6 87004689 1
Electric trans-
former
7 87001706 1 Plinth
8 87003603 2
Electric lamp unit
9 87004699 1 Din rail support 15x5
10 87004698 1 Din rail 15x5 L=130
11 87004091 1 Time relay
12 87004266 1 Potentiometer
ABB
13 87004697 20
Din rail connec-
tion block
2.5/15
14 87004696 2 Bulb 24V / 40W E27
15 87004670 1 Din rail 35x7.5 L=260
16 87004670 1 Din rail 35x7.5 L=325
17 87004670 1 Din rail 35x7.5 L=330
18 87004670 1 Din rail 35x7.5 L=80
19 87000946 4 Washer BRB 4.3
20 87000503 1 Washer BRB 5.3
21 87004695 2 Flex channel
22 87003647 1 Flex pvc pipe
23 87003645 1 Flex pvc pipe
24 87003652 1 Cable connector
For inductor
25 87003670 2 Clamp
26 87003671 2
Clamp
27 87003278 5 Screw cap
28 87003648 2 Screw cap
29 87003828 7 Screw cap
30 87003653 2
Screw cap
31 87003654 1 Screw cap
32 87003672 7 Nut
15.2
33 87003655 4 Nut 22
34 87004288 2 Screw cap
35 87003567 1 Fuse
4A
36 87003569 1 Circuit breaker 2A 1P
37 87000892 1 Circuit breaker 10A 3P
38 87003616 23 Plinth
DK 4/35
39 87003618 1 Fuse holder ASK-1/35
40 87003624 10
Din rail connec-
tion block
Brown
41 87004694 2
Din rail connec-
tion block
Blue
42 87003626 5
Din rail connec-
tion block
Green
Ref� No� Product No� Qty Description Specification
43 87003623 3 Din rail support
WEW 35/2
44 87000895 3 Contactor
45
87004761 1
Electric soft
starter, 3-p, 230 V
87004762 1
Electric soft
starter, 3-p, 400V
87004762 1
Electric soft
starter, 3-p, 440V
46 87004684 1 Button Man/aut
47 87004679 1 Button Light
48 87004683 1 Button Rotation
49 87004682 1 Button Spindle
50 87004678 1 Button Emergency
51 87004680 1 Button Reset
52 87004677 1 Joystick
53 87003791 1 Inductor
54 87005345 1 Safety relay 24V NSR
55 87004692 1 Socket
56 87004691 1 Relay 24V
57 87003622 1 Socket
58 87003607 4 Relay
59 87004899 2 Time relay
60 87004690 2 Electric wire L = 2.5 m
61 87004733 5 Rectifier
62 87003783 1 Switch
63 87000504 1 Nut
M5
64 87000838 1 Nut M6
65 87001958 2 Screw 5x35
66 87000945 1 Screw 6x12
67 87000693 1 Screw 4x6
68 87001209 2 Screw 5x6
69 87003912 26 Screw 8x16
70 87004634 1 Screw 5x12
71 87000896
1
Circuit breaker
LRD 07 230V,
1-p
1
LRD 07 230V,
3-p
1 LRD 07 ≥380V
72
87003933 1 Circuit breaker
LRD 16 230V
87003934 1 Circuit breaker LRD 12 ≥380V
73
87000977 1 Circuit breaker
LRD 06 230V
87000897 1 Circuit breaker LRD 05 ≥380V
74 87001901 4 Rivet 4 X 10
75 87004739 1 Screw cap
