Epiroc SB 52 - Technical Data; Machine Data

Technical data
Machine data
SB 52 SB 102 SB 152 SB 202 SB 302 SB
302
Tunnel
SB 452 SB
452
Tunnel
SB 552
Part
number
8460 0300
10
8460 0300
30
8460 0300
40
8460 0300
50
8460 0300
60
8460 0300
63
8460 0300
70
8460 0300
73
8460 0300
80
Service
weight, kg
(lb)
55 (120) 90 (190) 140 (310) 200 (440) 300 (670) 315 (692) 440 (970) 450 (996) 520 (1150)
Delivery
weight kg
(lb)
44 (97) 68 (150) 110 (243) 155 (392) 224 (494) 229 (505) 321 (708) 328 (723) 390 (860)
Suitable
carrier
weight
class,
tonnes (lbs)
0.7–1.1
(1,550-
2,400)
1.1–3.0
(2,400-
6,600)
1.9–4.5
(4,200-
9,900)
2.5–6.0
(5,500-
13,250)
4.5-9.0
(9,900-
19,840)
4.5-9
(9,900-
19,840)
6.5-13
(14,300-
28,650)
6.5-13
(14,300-
28,650)
9.0-15
(19,840-
33,100)
Working
length of
working tool
in standard
version,
mm (in.)
255
(10.0)
265
(10.4)
280
(11.0)
330
(13.0)
400
(15.7)
450
(17.6)
470
(18.5)
520
(20.4)
495
(19.5)
Working
tool
diameter,
mm (in.)
40 (1.57) 45 (1.77) 50 (1.97) 65 (2.56) 80 (3.15) 80 (3.15) 95 (3.74) 95 (3.74) 100 (3.94)
Start up
mode
AutoStart AutoStart AutoStart AutoStart AutoStart AutoStart AutoStart AutoStart AutoStart
Hose inside
diameter P,
mm (in.)
10
(⅜)
12
(½)
12
(½)
12
(½)
19
(¾)
19
(¾)
19
(¾)
19
(¾)
25
(1)
Hose inside
diameter T,
mm (in.)
10
(⅜)
12
(½)
12
(½)
12
(½)
19
(¾)
19
(¾)
19
(¾)
19
(¾)
25
(1)
SB 52, 102, 152, 202, 302, 302Tunnel, 452, 452Tunnel,
552
Safety and operating instructions
© Construction Tools PC AB | 9800 0648 01 | 2018-01-01
Original instructions
25
