Epiroc SB 52 - Capacities

Capacities
SB 52 SB 102 SB 152 SB 202 SB 302 SB 302
Tunnel
SB 452 SB 452
Tunnel
SB 552
Oil flow,
l/min (gpm)
12–27
(3.0-7.0)
16–35
(4.0-9.0)
25–45
(6.5-12.0)
35–65
(9.2-17.2)
50–80
(13.0-21.0)
50–80
(13.0-21.0)
55-100
(14.5-26.5)
70-100
(18.5-26.5)
65–115
(17.0-30.0)
Impact rate,
bpm
750–1,700 750–2,300 850–1,900 850–1,800 600-1,400 950-1,250 550-1,250 850-1,150 650–1,150
Operating
pressure,
bar (psi)
100–150
(1,450-
2,175)
100–150
(1,450-
2,175)
100–150
(1,450-
2,175)
100–150
(1,450-
2,175)
100–150
(1,450-
2,175)
100–110
(1,450-
1,595)
100–150
(1,450-
2,175)
100-110
(1,450-
1,595)
100–150
(1,450-
2,175)
Maximum
hydraulic
input power,
kW
7 9 11 17 20 15 25 19 29
Back
pressure
acceptance,
bar (psi)
25
(360)
18
(260)
25
(360)
25
(360)
26
(360)
26
(377)
21
(305)
21
(305)
18
(260)
Accumulato
r gas
pressure,
bar (psi)
40
(580)
40
(580)
40
(580)
40
(580)
40
(580)
40
(580)
40
(580)
40
(580)
40
(580)
Pressure
relief valve
on breaker,
bar (psi)
180
(2,611)
180
(2,611)
180
(2,611)
170
2,466)
185
(2,683)
185
(2,683)
185
(2,683)
185
(2,683)
185
(2,683)
Water
pressure,
bar (psi)
- - 4
(58)
4
(58)
4
(58)
4
(58)
4
(58)
4
(58)
4
(58)
Water
consumptio
n, l/min
(gpm)
- - ≤5
(≤1.3)
≤5
(≤1.3)
≤9
(≤2.4)
≤9
(≤2.4)
≤9
(≤2.4)
≤18
(≤4.8)
≤9
(≤2.4)
Air
pressure,
bar
(psi)
2
(29)
2
(29)
2
(29)
2
(29)
2
(29)
2
(29)
2
(29)
2
(29)
2
(29)
Air flow,
m
3
/min (ft
3
/
min)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
≤0.73
(≤26)
