Episode EA-RSP-16D-100 User Manual

page | 14
www.snapav.com Support 866.838.5052
SPECIFICATIONS
General
Specification EA-RSP-8D-100 EA-RSP-12D-100 EA-RSP-16D-100 EA-RSP-2D-200
Analog inputs
Stereo RCA inputs
4 pair 6 pair 8 pair 1 pair
Analog loop outputs
Stereo RCA outputs
4 pair 6 pair 8 pair 1 pair
Speaker outputs
8 channels: 4 stereo
or bridged outputs
12 channels: 6 stereo
or bridged outputs
16 channels: 8 stereo
or bridged outputs
2 channels: 1 stereo
or bridged output
Trigger control
1 x 3.5 mm (in, 4.5V-12V DC), 1 x 3.5 mm (out,12V DC)
Trigger voltage range
(external)
4.5V-12V DC
IR control
1 x 3.5 mm (in), 1 x 3.5 mm (out)
IR power
+12V provides +12V DC to power an IR receiver unit, on/off selectable
IR voltage range
2V-12V
Audio specifications
Specification EA-RSP-8D-100 EA-RSP-12D-100 EA-RSP-16D-100 EA-RSP-2D-200
Frequency response
20 Hz to 20 kHz, ±2 dB at 1/8 power
Subwoofer output frequency band
20 Hz to 200 Hz, fixed - biquad low-pass filter at 200 Hz, 6 dB/octave slope
Analog loop outputs
Output 2 Vrms at 10K ohm impedance load
Power output @ 8Ω, 2 channels driven
2x50W 1 kHz 2 × 100W 1 kHz
Power output @ 4Ω, 2 channels driven
2x100W 1 kHz 2 × 200W 1 kHz
Power output @ 8Ω, all channels driven
8x50W 1 KHz 12x50W 1 kHz 16x50W 1 kHz 2 × 100W 1 kHz
Power output @ 4Ω, all channels driven
8x100W 1 KHz 12x85W 1 kHz 16x80W 1 kHz 2 × 200W 1 kHz
Power output bridged @ 8Ω
4x200W 1 KHz 6x170W 1 kHz 8x160W 1 kHz 1 × 400W 1 kHz
Minimum impedence
2 ohm 1 ohm
Auto sensing sensitivity
2.5 mVrms
Input sensitivity
1 Vrms
Input impedance
RCA analog input: 20kΩ
RCA analog input:
22kΩ
Input gain control
Compensate for wide range of sources input levels from 0.5 Vrms to 4 Vrms
Total harmonic distortion @1W, 1 kHz
<0.05%
Total harmonic distortion @50W, 1 kHz
1% 1% @ 100W
Signal-to-noise ratio
>95 dB A-weighted @ rated power
Frequency response
20 Hz - 20 kHz < ± 2 dB
Crosstalk
< -60 dB @ all channels
Dynamic range: S/N ratio
> 100 dB A-weighted @ rated power
THD
0.01% 1 kHz @1/8 rated power 4Ω or 8Ω
0.01% 1 kHz @1/8
rated power 4Ω
or 8Ω
