Toilet installation
Draw drain outlet centerline on the floor.
Install angle valve at proper position on
the wall according to the dimension of
toilet.
1. Installation of angle valve
Note:
1. Please use the supplied angle valve when
installing this toilet. Use of another angle
valve not including a filter may result in
blockages in the toilet and bidet waterways.
2. If replacing an existing angle valve, please
contact a professional for installation.
305mm
Drain outlet
2. Cardboard installation
Align cardboard with the centerline of
drain outlet.
Draw contour line according to cardboard.
3. Hose
Connect the water inlet and angle valve
of the toilet with the matching hose and
tighten it.
Note:
Please use this supplied water supply hose,
to ensure optimal flushing performance.
Connect the water inlet
hose of the toilet seat
Connect the water supply
hose of the toilet tank
the water supply hose
of the toilet tank
the water inlet hose
of the toilet seat
Installation Method 1:
NPT 1/2
5/8′′
Installation Method 2:
Line
Drain outlet
Equipped with three-way angle valve
10
