Poll Status
Command
The following 8‐byte Modbus command may be sent in order to poll the status of the IPES‐ IR3:
8‐byte Modbus command
Byte
Description
0
Current Modbus address (247 if IPES‐IR3 set to factory default.
1
4 (Modbus function code for reading from the device)
2
0
3
1
4
0
5
1
6
Low byte of 16‐bit CRC
7
High byte of 16‐bit CRC
The IPES‐IR3 responds with a 7‐byte packet with the following format:
7 byte Poll Status Command
Byte
Description
0
Current Modbus address
1
4 (Modbus function code for reading from the device)
2
2
3
Status:
Bit 0: 1 = fast detection, 0 = slow detection
Bit 1: 1 = high sensitivity, 0 = medium sensitivity
Bit 2: 1 = latching on, 0 = latching off
Bit 3: 1 = fire relay enable, 0 = fire relay disable
Bit 4: 1 = fault relay enable, 0 = fault relay disable
Bit 5: 1 = heater enable, 0 = heater disable
Bit 6: 1 = very high sensitivity enable,
0 = very high sensitivity disable
Bit7: not used
4
Detector status
Bit 0: 1 = fire detected, 0 = no fire detected
Bit 1: 1 = hardware fault, 0 = no hardware fault
Bit 2: 1 = dust fault, 0 = no dust fault
Bits 3‐7: not used.
5
Low byte of 16‐bit CRC
6
High byte of 16‐bit CRC
Sending any commands other than the ones specified is not
permitted.
