Step 3: Mark Holes
Mark the four (4) mounting hole locations on the mounting surface.
Step 4: Drill Holes
Remove the controller and drill four sizeable holes in the marked locations.
Step 5: Secure Controller
Place the controller on the surface and align the mounting holes with the drilled holes
in step 4. Secure the controller in place using the mounting screws.
3.3 Wiring
NOTE: A recommended connection order has been provided for
maximum safety during installation.
NOTE: Do not entangle all wiring together, communication cable and
power wires should be as far away as possible, to prevent interfering
communication signal transmission.
NOTE: The eTracer is a negative ground controller. Any negative
connection of solar or battery can be earth grounded as required.
Grounding is recommended.
CAUTION: For mobile applications, be sure to secure all wiring. Use
cable clamps to prevent cables from swaying when the vehicle is in
motion. Unsecured cables create loose and resistive connections which
may lead to excessive heating and/or fire.
Step 1: Remote Temperature Sensor Connection
NOTE: The controller will not perform temperature compensation for
charging parameters if the RTS300RA is not used.
CAUTION: Equipment Damage! Never place the temperature sensor
inside a battery. Both the RTS300RA and the battery will be damaged.
