8.0 Specifications
Electrical
ET2415N ET3415N ET4415N ET6415N
Nominal System Voltage 12V / 24V / 36V / 48V dc
Nominal Battery Current 20A 30A 45A 60A
Maximum Solar Input Voltage 150V dc
Battery Voltage Range 8～72V dc
Maximum Input Power
12V： 260W 400W 600W 800W
24V： 520W 800W 1200W 1600W
36V： 780W 1200W 1800W 2400W
48V： 1040W 1600W 2400W 3200W
Self Consumption 1.4～2.2W
Grounding Solar or Battery Negative Terminal
Remote Temperature Sensor Port MC1.5-3.81-2L
Remote Battery Voltage Sense Port MC1.5-3.81-2L
CAN BUS Port MC1.5-3.81-4L
Ethernet Port RJ45
Serial RS-232 Port DB9, male
Settings
Charging Stages MPPT，Boost / Equalize，Float
Temp. Compensation Range -25℃ ~ +55℃
Temp. Compensated Setpoints Equalize，Boost，Float，LVD
