Page 25
5.0 Networking & communication
5.1 Introduction
Note: Windows XP /windows 7 are recommended!
IE7.0 or above is recommended!
Can’t compatible with the safari browser of Mac OS X!
CAUTION: Risk of Tampering!
The eTracer doesn’t feature built-in network security. It is the
responsibility of the user or network administrator to install the
eTracer behind a network firewall to prevent unauthorized access.
The Ethernet port supports HTTP, TCP/IP protocols to provide a fully web-enabled
interface between the eTracer and a LAN network. Features the Ethernet connection
provides include:
• Monitor the controller from a web browser
• Modify controller settings from a web browser
This section provides a summary of each of the features. For detailed information
about Ethernet connectivity and networking, please refer to our website at:
http://www.epsolarpv.com/
Network Information
Connect the controller directly to a PC using an Ethernet cross-over cable, or using
standard cable to exchanger. Use CAT-5 or CAT-5e twisted pair Ethernet cables with
RJ-45 connectors.
Factory default network Settings refer to Table 4.4.3.
2 LED’s on the Ethernet jack indicate link and activity status.
