Page 41
③
Voltage parameters in strict accordance with:
a. Over Volt. Disc＞Charge Limit＞Equalize Charge＞Boost Charge＞Float
Charge＞Boost Volt. Rect.
b. Under Volt. Rcvr＞Under Volt. Warn＞Low Volt. Disc＞Discharge Limit.
④
Parameters will be displayed as corresponding default values after correct system
voltage identification.
Mechanical:
L x W x H Mounting Net Weight
ET2415N 206 x 203 x 105 mm 150 x 193 mm 2.6kg
ET3415N 231 x 203 x 105 mm 150 x 193 mm 4.1kg
ET4415N 285 x 203 x 105 mm 200 x 193 mm 4.4kg
ET6415N 285 x 203 x 121 mm 200 x 193 mm 5.0kg
Terminal: 35mm
2
Mounting hole: Φ10（M8）
Environmental
Ambient Temp. -25℃ ～ +55℃
Storage Temp. -30℃ ～ +85℃
Humidity 10 ～ 90% N.C.
Altitude ≤3000 m
Enclosure IP20
