4
Installation Location
• Before installing the projector, verify the power supply wiring for the installation location.
• If you want to hide the projector power plug under the wall plate cover, make sure the power outlet is
located in the empty space to the left or right of the wall plate and is between 3.7 inches (93.5 mm) and
4.9 inches (123.5 mm) from the center of the wall plate (not the center of the projection surface). If the
outlet is more than 4.9 inches (123.5 mm) from the center of the wall plate, the power plug will not fit
under the cover.
• Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some
kinds of fluorescent lights could interfere with the remote control of the projector.
• Install the projector away from direct sunlight and other bright light sources.
• Make sure there is at least 20 inches (50 centimeters) of space between the wall and the projector's air
exhaust and intake vents on the left and right.
• It is recommended to keep VGA computer cable length less than 65 feet (20 meters) to reduce external
noise.
• Install the projector at an angle of no more than 3° horizontally or vertically in relation to the projection
surface.
• Install the projector in a location where the projected image is within reach.
• When installing two or more projectors, make sure the temperature of the surrounding environment is
less than 95°F (35°C). If the environment is too hot, the projectors may overheat and the power may turn
off without warning.
• The projector must be installed in one of the following locations in order for the Touch Unit to function
properly (if applicable):
• Mounted on a wall or suspended from the ceiling with images projected from in front of the screen.
• Mounted vertically on a table with images projected from the front of the table. If using this
installation method, you need the optional interactive table mount (ELPMB29).
