Installation Instructions CHF4000/4500
4
DIMENSIONS
.88
22
2.72
69
5.36
136
ROLL ADJUSTMENT
POINT
3
YAW ADJUSTMENT
POINT
20
.28
7
4.61
117
PITCH ADJUSTMENT
POINT
20
6.50
165
5.50
140
4.50
114
5.50
140
.84
21
1.69
43
.84
21
1.69
43
2.25
57
2.75
70
1.50" DIA NPT
DIMENSIONS: [MILLIMETERS]
INCHES
