Air Filter and Vent Maintenance
143
Regular filter maintenance is important to maintaining your projector. Clean
the air filer when a message appears telling you the temperature inside the
projector has reached a high level. It is recommended that you clean these
parts over a 2000-hour period. Clean them with shorter periodicity if you use
the projector in a particularly dusty environment.
Attention
If regular maintenance is not performed, your Epson projector will notify you
when the temperature inside the projector has reached a high level. Do not wait
until this warning appears to maintain your projector filter as prolonged exposure
to high temperatures may reduce the life of your projector or lamp.
gg Related Links
"Cleaning the Air Filter and Vents" p.143
"Replacing the Air Filter" p.143
Cleaning the Air Filter and Vents
Clean the projector's air filter or vents if they get dusty, or if you see a
message telling you to clean them.
a
Turn off the projector and unplug the power cord.
b
Gently remove the dust using a small vacuum designed for computers
or a very soft brush (such as a paintbrush).
a
You can remove the air filter so that you can clean both sides. Do
not rinse the air filter in water, or use any detergent or solvent to
clean it.
Attention
Do not use canned air. The gases may leave a flammable residue or push
dust and debris into the projector's optics or other sensitive areas.
c
If dust is difficult to remove or the air filter is damaged, replace the air
filter.
Replacing the Air Filter
You need to replace the air filter in the following situations:
After cleaning the air filter, you see a message telling you to clean or replace
it
The air filter is torn or damaged
You can replace the air filter while the projector is mounted to the ceiling or
placed on a table.
a
Turn off the projector and unplug the power cord.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-1795F and is the answer not in the manual?

Epson EB-1795F Specifications

General IconGeneral
Matrix size0.59 \
Number of colors1.07 billion colors
Native aspect ratio16:9
Projection distance1.35 - 1.62 m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Contrast ratio (typical)10000:1
Screen size compatibility30 - 300 \
Projection distance (tele)0.8 - 8.2 m
Projection distance (wide)0.7 - 6.8 m
Projector native resolution1080p (1920x1080)
Keystone correction, vertical-30 - 30 °
Keystone correction, horizontal-20 - 20 °
Projector brightness (economic mode)1900 ANSI lumens
3DNo
Full HDYes
Video processing10 bit
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Supported video modes1080p
Analog signal format system-
Supported graphics resolutions1920 x 1080 (HD 1080)
Lamp power214 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)7000 h
Noise level39 dB
Country of originPhilippines
Noise level (economic mode)30 dB
FocusManual
Throw ratio1.02 - 1.23:1
Focal length range13.52 - 16.22 mm
Aperture range (F-F)1.58 - 1.7
USB 2.0 ports quantity2
S-Video inputs quantity0
Standard interfacesHDMI, NFC, USB, VGA, Wireless LAN
USB display function3 in 1: Image / Mouse / Sound
Sustainability certificatesTCO
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite, Grey
Market positioningBusiness
Cable lock slot typeKensington
RMS rated power1 W
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.34 W
Power consumption (typical)295 W
Power consumption (economy mode)208 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Multi PC Projection
Pallet width800 mm
Pallet height150 mm
Pallet length1200 mm
Pallet weight0 g
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet70 pc(s)
Quantity per pallet (UK)84 pc(s)
Quantity per pallet layer5 pc(s)
Harmonized System (HS) code85286200
Quantity per pallet layer (UK)6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth213 mm
Width292 mm
Height44 mm
Weight1800 g
Package depth420 mm
Package width370 mm
Package height145 mm
Package weight3730 g
