Controlling a Presentation with Your Hands
73
An adjustment screen is displayed with markers on the side of the
screen. When using the Gesture Presenter feature, the image is slightly
smaller.
f
Cover one of the following markers on the screen with your hand.
Remove your hand while the color of the icon next to the marker is
changing.
To move to the next slide or page, cover the marker next to the
icon.
To move to the previous slide or page, cover the marker next to the
icon.
a
Stand away from the markers to prevent them from being
covered accidentally when you do not want to perform the
operations.
The markers are not available for the following input sources.
Computer (component video)
Video
USB-A
LAN (Epson iProjection)
Screen Mirroring (if the device does not support User
Interface Back Channel (UIBC))
For HDMI and Computer (RGB) image sources, you can use
the markers with Windows 2000 and later, or OS X 10.5.x and
later.
g
To close the Gesture Presenter, press the [Gesture] button.
a
You can also close the Gesture Presenter by pressing the [Screen
Fit] button on the control panel, or by selecting Start/Stop in the
projector's Settings menu.
s Settings > Gesture Presenter > Start/Stop
gg Related Links
"Gesture Presenter Restrictions" p.73
Gesture Presenter Restrictions
Operating restrictions
You cannot change the following settings while using the Gesture Presenter
feature.
Auto Source Search (set to Off automatically)
Auto Iris (set to Off automatically)
Light Optimizer (set to Off automatically)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-1795F and is the answer not in the manual?

Epson EB-1795F Specifications

General IconGeneral
Matrix size0.59 \
Number of colors1.07 billion colors
Native aspect ratio16:9
Projection distance1.35 - 1.62 m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Contrast ratio (typical)10000:1
Screen size compatibility30 - 300 \
Projection distance (tele)0.8 - 8.2 m
Projection distance (wide)0.7 - 6.8 m
Projector native resolution1080p (1920x1080)
Keystone correction, vertical-30 - 30 °
Keystone correction, horizontal-20 - 20 °
Projector brightness (economic mode)1900 ANSI lumens
3DNo
Full HDYes
Video processing10 bit
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Supported video modes1080p
Analog signal format system-
Supported graphics resolutions1920 x 1080 (HD 1080)
Lamp power214 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)7000 h
Noise level39 dB
Country of originPhilippines
Noise level (economic mode)30 dB
FocusManual
Throw ratio1.02 - 1.23:1
Focal length range13.52 - 16.22 mm
Aperture range (F-F)1.58 - 1.7
USB 2.0 ports quantity2
S-Video inputs quantity0
Standard interfacesHDMI, NFC, USB, VGA, Wireless LAN
USB display function3 in 1: Image / Mouse / Sound
Sustainability certificatesTCO
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite, Grey
Market positioningBusiness
Cable lock slot typeKensington
RMS rated power1 W
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.34 W
Power consumption (typical)295 W
Power consumption (economy mode)208 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Multi PC Projection
Pallet width800 mm
Pallet height150 mm
Pallet length1200 mm
Pallet weight0 g
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet70 pc(s)
Quantity per pallet (UK)84 pc(s)
Quantity per pallet layer5 pc(s)
Harmonized System (HS) code85286200
Quantity per pallet layer (UK)6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth213 mm
Width292 mm
Height44 mm
Weight1800 g
Package depth420 mm
Package width370 mm
Package height145 mm
Package weight3730 g
