Epson EB-440W User Manual

Front/Top
Name Function
A
Remote Receiver
Receives signals from the remote control.
s Quick Start Guide
B
Lamp cover
Open this cover when replacing the projector's Lamp.
s p.112
C
Lamp Cover Fixing
Screw
Screw to fix the Lamp cover in place. s p.112
D
Air exhaust vent
Exhaust vent for air used to cool the projector internally.
Caution
While projecting, do not put your face or hands
near the air exhaust vent, and do not place objects
that may become warped or damaged by heat near
the vent.
Name Function
E
Cable cover fixing
screws
Screws to fix the cable cover in place.
s Quick Start Guide
F
Cable cover
When connecting to an input port, loosen the two screws
and open this cover.
s Quick Start Guide
G
Control panel
Allows you to operate and check the status of the
projector. s p.15
H
Speaker
Outputs audio from the Microphone (Mic) and the image
currently being projected.
Part Names and Functions
11

Epson EB-440W Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1600:1
Projector native resolution	WXGA (1280x800)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	369 x 481 x 115 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3500 h
RMS rated power	10 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	1 W

Weight and Dimensions

Weight	5700 g
