Name Function
T
[User] button
Select any frequently used item from the five available
Configuration Menu items, and assign it to this button. By
pressing the button the assigned menu item selection/
adjustment screen is displayed, allowing you to make one-
touch settings/adjustments. s p.76
The menu Power Consumption is assigned as the default
setting.
U
[USB] button
Each time you press the button, input changes between
images from the equipment connected to USB Display
and USB(TypeA) port. s p.22
V
[LAN] button
Changes to the images projected with EasyMP Network
Projection. When you are projecting via Quick Wireless
Connection using the optional Quick Wireless
Connection USB Key, pressing this button changes to that
image. s p.22
W
[Source Search]
button
Changes to images from the next device inputting an
image signal. s p.21
X
Remote control light-
emitting area
Outputs remote control signals.
Easy Interactive Pen(EB-465i/455Wi Only)
Name Function
A
Pen tip switch
Functions as the left button of a mouse.
B
Battery indicator
When you press the button, this indicator lights green if
there is any remaining battery power.
It does not light if there is not much remaining battery
power. If this happens, replace the batteries. s p.62
C
Button
Functions as the right button of a mouse.
D
Strap attachment hole
You can attach a commercially available strap.
E
Battery cover
Open this cover when replacing the batteries. s p.62
Part Names and Functions
18
