Name Function
E
[w][v] buttons
Corrects Keystone distortion. In the following cases,
however, these buttons function as the [
] and [ ]
buttons.
– When the projected image is being sent through a
Network connection
– When the Slideshow function is being used for
projection
If pressed when a Configuration Menu or Help screen is
displayed, these buttons selects menu items and setting
values.
s Quick Start Guide , p.73
F
[Help] button
Displays and closes the Help screen which shows you how
to deal with problems if they occur. s p.93
G
[Esc] button
Stops the current function.
When the Configuration Menu is displayed, pressing this
button moves to the previous menu level. s p.73
H
[Wide][Tele] button
Adjusts Tele/Wide. Press the [Tele] button to reduce the
size of the projection screen and press the [Wide] button
to increase the size of the projection screen.
When the Configuration Menu or Help screen is
displayed, these buttons function as the [
][ ] buttons,
which select menu items and setting values.
s Quick Start Guide
I
[Menu] button
Displays and closes the Configuration Menu.
s p.73
Remote Control
Part Names and Functions
16

Epson EB-440W Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1600:1
Projector native resolution	WXGA (1280x800)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	369 x 481 x 115 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3500 h
RMS rated power	10 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	1 W

Weight and Dimensions

Weight	5700 g
