Submenu Function
Position
You can adjust the display position up, down, left, and right when
a part of the image is missing so that the whole image is projected.
Auto Setup
(Only available when an analog RGB computer signal is being
input.)
Set to On to automatically adjust Tracking, Sync., and Position to
the optimum state when the input signal changes.
Overscan
Changes the output image ratio (the range of the projected
image). You can set the cropping range to 4% or 8%. When set to
Auto, this is automatically adjusted according to the input signal.
Blanking
You can hide images in the set area. Use the [
][ ] buttons to
adjust the area. You can adjust by using a combination of Top,
Bottom, Left, and Right.
Advanced
You can set by choosing the following items.
Video Range: Select the video range for the input signal from the
HDMI port, DVI-D port, HDBaseT port, or SDI. Set to
Expanded if you are concerned about misadjusted black levels or
blown out highlights in the image.
Input Signal: Select an input signal from the Computer port or
BNC port. If set to Auto, the input signal is set automatically
according to the connected equipment. If colors do not appear
correctly when set to Auto, select the appropriate signal
according to the connected equipment.
Image Processing: Changes settings for image processing.
• Fine: When Frame Interpolation is On, Frame Interpolation
is enabled.
• Fast 1: Images are displayed quicker without any loss in image
quality.
• Fast 2: Images are displayed quicker than Fast 1.
Scale
When using multiple projectors to project one image, adjust the
range of the image displayed by each projector.
s "Displaying a Scaled Image" p.102
Submenu Function
Reset
You can reset all adjustment values on the Signal menu to their
default settings, except for Input Signal.
See the following to return all menu items to their default
settings.
s "Reset Menu" p.146
List of Functions
130

Epson EB-L1505U Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.99 - 27.77 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	60 - 500 \
Projection distance (tele)	3.3 - 27.8 m
Projection distance (wide)	2 - 17.2 m
Projector native resolution	WUXGA (1920x1200)
Keystone correction, vertical	-45 - 45 °
Keystone correction, horizontal	-30 - 30 °
Built-in display	Yes
Display diagonal	1.03 \
Throw ratio	1.57 - 2.56:1
Focal length range	36 - 57.35 mm
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-18 - 18 %
Lamp power	670 W
Light source type	Lamp
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
3D	No
Video color modes	Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Audio (L/R) in	3
Audio (L/R) out	1
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	30 dB
Placement	Desktop
Product type	Large venue projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	908 W
Power consumption (economy mode)	597 W
Cables included	AC, VGA
Pallet width	800 mm
Pallet height	150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	492 mm
Width	586 mm
Height	211 mm
Weight	23800 g
Package depth	780 mm
Package width	750 mm
Package height	325 mm
Package weight	33900 g
