Chan
nel
Function Operation Parameters Default Operation Content
4 Lens position Non-operational 0 - 31 0 Moves the lens shift to the home position.
Move to home position 32 - 63
Non-operational 64 - 255
5 Horizontal lens shift (+) lens adjustment Movement - Large 0 - 31 128 Performs horizontal lens shift using the amount of
movement specified.
Movement - Me-
dium
32 - 63
Movement - Small 64 - 95
Non-operational 96 -159
(-) lens adjustment Movement - Small 160 - 191
Movement - Me-
dium
192 - 223
Movement - Large 224 - 255
6 Vertical lens shift (+) lens adjustment Movement - Large 0 - 31 128 Performs vertical lens shift using the amount of
movement specified.
Movement - Me-
dium
32 - 63
Movement - Small 64 - 95
Non-operational 96 -159
(-) lens adjustment Movement - Small 160 - 191
Movement - Me-
dium
192 - 223
Movement - Large 224 - 255
7 Electronic zoom (+) lens adjustment Movement - Large 0 - 31 128 Performs electronic zoom using the amount of movement
specified.
Movement - Me-
dium
32 - 63
Movement - Small 64 - 95
Non-operational 96 -159
