Before performing edge blending to raise the precision of adjustments,
press the [Color Mode] button on the remote control, and then set
Color Mode to Multi-Projection.
a
Press the [Menu] button while projecting.
b
Select Multi-Projection from Extended.
c
Select Edge Blending, and then press the [ ] button.
The following screen is displayed.
Submenu Function
Edge Blending
Set to On to activate Edge Blending. Set to Off
when not projecting from multiple projectors.
Submenu Function
Top Edge/Bottom
Edge/Left Edge/Right
Edge
Blending: Set to On to activate Edge Blending
towards your settings, and the blend range will be
shaded.
Blend Start Position: Displays blending start
position as a red line, and adjusts at the level of one
pixel.
Blend Range: Adjusts the range to be shaded.
Adjustment is possible at the level of one pixel. The
maximum range is 45% of the resolution.
Blend Curve
You can select from three ways of shading.
Guide Display
Set to On to display a guide on the Edge Blending
setting range.
Pattern Guide
Set to On to display a guide to match the position of
the Edge Blending setting range.
Guide Colors
Select a combination of guide colors from the three
provided.
d
Turn on Edge Blending.
(1)
Select Edge Blending, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
e
Set Guide Display to On.
(1)
Select Guide Display, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
a
If the guide is not clear, you can change the color of the guide
on Guide Colors.
Multi-Projection Function
94
