Epson EB-L615U Specifications

General

HDBaseT port	Yes
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	1
Mobile High-Definition Link (MHL)	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.4 - 23.84 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	50 - 500 \
Projection distance (tele)	2.4 - 23.8 m
Projection distance (wide)	1.4 - 14.8 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	4200 ANSI lumens
Video color modes	Bright cinema, Cinema, Dynamic, Presentation, sRGB
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	1.35 - 2.20:1
Focal length range	20 - 31.8 mm
Aperture range (F-F)	1.5 - 1.7
Vertical lens shift range	-50 - 50 %
Horizontal lens shift range	-20 - 20 %
Placement	Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
Auto power off	No
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	353 W
Power consumption (economy mode)	265 W
RMS rated power	10 W
Noise level	38 dB
Country of origin	China
Noise level (economic mode)	27 dB
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Pallet width	800 mm
Pallet height	2180 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	304 mm
Width	440 mm
Height	120 mm
Weight	8500 g
Package depth	564 mm
Package width	538 mm
Package height	208 mm
Package weight	11640 g
