Multi-Projection Features
123
You can combine the projected images from multiple projectors to create one
bright image or a large seamless image (Multi-Projection).
The number of projectors that can be used depends on the function and
method.
• Projecting one large image by compositing several images (tiling): up to 15
projectors
• Projecting a bright image by overlaying images (stacking)
• Using the Epson Projector Professional Tool software: up to 6 projectors
• Using the projector's menu: up to 2 projectors
gg Related Links
• "Procedure Overview" p.123
• "Preparing for Multi-Projection" p.123
• "Image Composition" p.125
• "Adjusting Colors" p.131
Procedure Overview
We recommend using the following procedure for Multi-Projection.
Preparation
• Initializing projectors
• Assigning a master projector
• Calibrating projectors
• Installing projectors
• Performing rough image adjustments
• Connecting projectors to a network
Image Composition
• Tiling
• Stacking
Adjusting colors
• Adjust the Hue, Saturation, and Brightness settings for individual image
colors.
• Adjust the overall tint of the image.
Preparing for Multi-Projection
This section explains how to perform basic settings before installing the
projector and preparing in advance for easier operations later.
gg Related Links
• "Initializing Projectors" p.123
• "Assigning a Master Projector" p.124
• "Calibrating Projectors" p.124
• "Installing Projectors" p.124
• "Performing Rough Image Adjustments" p.124
• "Connecting Projectors to a Network" p.125
Initializing Projectors
You need to correct the difference in settings for each projector.
Do the following operations for all projectors:
• Reset the projector settings to their default values.
s Reset > Reset All Config
• Reset the values on the Color Uniformity menu to their default settings.
s Extended > Display > Color Uniformity > Reset
• Reset the values on the Panel Alignment menu to their default settings.
s Extended > Display > Panel Alignment > Reset
• Set the Adjustment Level setting to All in the Color Matching menu, and
select 0 for Red, Green, and Blue.
s Extended > Multi-Projection > Screen Matching > Color Matching
• Set the 4K Enhancement setting to Off.
s Image > Image Enhancement > 4K Enhancement
• Set the Sleep Mode setting to Off.
s Extended > Operation > Sleep Mode
