Epson EB-X51 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 12 Revision A
1.2 Specifications
 EB-E01/X06/W06/E10/X51/W51/W52
Model
EB-E01 EB-X06 EB-W06 EB-E10 EB-X51 EB-W51 EB-W52
Item
Specific
ation
of main
part
LCD
Size
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.59 inch
(C2fine)
Pixel number
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
1,024,000 pixels
(1280 x 800) x 3
Native resolution XGA XGA WXGA XGA XGA WXGA WXGA
Aspect ratio 4:3 4:3 16:10 4:3 4:3 16:10 16:10
Projection Lens
Focus Type Manual
Zoom
Type Digital Manual Manual Digital Manual Manual Manual
Ratio 1-1.35 1-1.2 1-1.2 1-1.35 1-1.2 1-1.2 1-1.2
Lamp
Type UHE
Power consumption 210W
Life
Normal 6,000 hours
Eco 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,300lm 3,600lm 3,700lm 3,600lm 3,800lm 4,000lm 4,000lm
Eco mode
Color mode: Dynamic,
Zoom: Wide
2,200lm 2,400lm 2,400lm 2,200lm 2,500lm 2,600lm 2,600lm
Sound output Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding)
RCA — 1 (Yellow) 1 (Yellow) — 1 (Yellow) 1 (Yellow) 1 (Yellow)
Digital HDMI 1
Video output Analog D-sub 15pin —
Audio
Input
RCA (L/R)—11—111
Stereo mini —
Output Stereo mini —
Mic Input Stereo mini —

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
