EB-E01 series Troubleshooting INTERNAL USE ONLY

SEIKO EPSON 36 Revision A

2.3 Exterior Check

When repairing this product, carry out exterior check of the target parts/units as

necessary.

Target part Check items

Upper Case

Any damage/deformation/cracking due to external forces?

Is it fixed to Lower Case correctly?

Any foreign object/dirt on IR receiver?

Rear Case

Any damage/deformation/cracking due to external forces?

Is it fixed to Lower Case and in the frame correctly?

Control panel

Is it fixed to Upper Case correctly?

Are there any stuck buttons?

Do buttons work smoothly?

Lamp Cover Unit

Is it fixed to Upper Case correctly?

Any damage on the latch to operate the Interlock SW? (Remove the

lamp cover unit and check it.)

Projection Lens

Does FOCUS RING work smoothly?

Does Zoom Ring work smoothly?

Any dirt/scratches on the projection lens?

Lower Case

Any damage/deformation/cracking due to external forces?

Any foreign object/dirt on it?

Foot

Does Front Foot work smoothly to adjust height?

Does Rear Foot work smoothly to adjust height?

Any Foot Rubber detached?

AC Inlet

Any deformation/discoloration on the connector/terminals?

Any damage on the socket?

Interface

(Connector part)

Any deformation/discoloration on the connector/terminals?

Any foreign objects on the connectors/terminals?

Air Filter

Is it fixed correctly?

Is there any dirt or foreign substance on the filter?

(Remove the air filter and check it.)

Is there any dirt/foreign substance on the fan inside the filter?

Lens Shutter

Any deformation/discoloration on it?

Is it fixed to Upper Case correctly?

Does it work smoothly?

Lamp

Any deformation/discoloration on the frame?

Any deformation/discoloration on the connector?

Any dirt on the glass surface?

Target part Check items
