Epson EB-X51 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 166 Revision A
3.9 Part Names List
Part names are written as abbreviations in this manual. Below is the
correspondence table of the abbreviations and SPI notation of the part names.
PART NAMES LIST
Name used in this manual SPI Parts Name
Optical Engine Assy
OPT ENGINE ASSY-X;H971;PH;AS
OPT ENGINE ASSY-X;H972;PH;AS
OPT ENGINE ASSY-X;H975;PH;AS
OPT ENGINE ASSY-X;H976;PH;AS
OPT ENGINE ASSY-X;H981;PH;AS
OPT ENGINE ASSY-X;H982;PH;AS
OPT ENGINE ASSY-X;HA03;PH;AS
OPT ENGINE ASSY-X;H986;PH;AS
OPT ENGINE ASSY-WX;H973;PH;AS
OPT ENGINE ASSY-WX;H983;PH;AS
OPT ENGINE ASSY-WX;H987;PH;AS
OPT ENGINE ASSY-FH;H974;PH;AS
OPT ENGINE ASSY-FH;H978;PH;AS
OPT ENGINE ASSY-FH;H979;PH;AS
OPT ENGINE ASSY-FH;H980;PH;AS
Lamp Assy LAMP ASSY;H950;AS
Lower Case
CASE UNIT,LOWER;K1-WH;PH
CASE UNIT,LOWER;K1-BK;PH
CASE UNIT,LOWER;D1-WH;PH
CASE UNIT,LOWER;D1-BK;PH
RC Filter FILTER,RC
Front Foot FOOT UNIT,FRONT
Rear Foot FOOT,REAR,AS_CKD
Lower Shield Plate A SHIELD PLATE,LOWER;A;PH
Lower Shield Plate B SHIELD PLATE,LOWER;B;PH
FB Insulation Sheet SHEET,INSULATION,FB;H838;PH
Filter Board FILTER BOARD UNIT;H838;PI;2
Inlet Cable CABLE,INLET-H838;PH
IR Board PCB ASSY;H980IR-MP;PH
RCF Cable CABLE,RC FRONT-H850;PH;2
PS Holder HOLDER,PS
Lower Cushion Seal CUSHION,SEAL,LOWER;H850;PH
Lower Cushion CUSHION,LOWER;H850;PH
Inlet Fasten Plate
PLATE,FASTEN,INLET;KH;PH
PLATE,FASTEN,INLET;V16H;PH
INT Duct A
DUCT,INTAKE;A;K;PH
DUCT,INTAKE;A;D;PH
INT Duct B
DUCT,INTAKE;B;K;2;PH
DUCT,INTAKE;B,H978;PH
DUCT,INTAKE;B,H980;PH
INT Fan FAN;SR7039-THT-H838
Cable Fasten Tape TAPE,CABLE FASTEN;PH
INT Duct Cushion Seal C CUSHION,SEAL,DUCT INTAKE;C-H850;PH
INT Duct Cushion Seal D CUSHION,SEAL,DUCT INTAKE;D-H850;PH
TH Board PCB ASSY;H980TH-MP;PH
TH Cable H550 CABLE,TH-H550;PH;2
TH Cable H309 CABLE,TH-H309;PH;2
P4combo Module P4combo module;MP
FFC 15P FFC,SHIELD,15-H978
Lower Conduction Plate
PLATE,CONDUCTION,LOWER;K;2;PH
PLATE,CONDUCTION,LOWER;V;PH
Conduction Cushion CUSHION,CONDUCTION;PH
PS Ballast Assy PS BALLAST UNIT ASSY;H838;EP;PH2;5
Cable PS-MA CABLE,PS-MA-H838-B;PH;2
Cable PS-FB CABLE,PS-FB-H838;PH
Cable BA-Lamp CABLE,BA-LAMP-H838
PS Shield Plate
SHILED PLATE,PS;A;PH
SHIELD PLATE,PS;B;PH
Name used in this manual SPI Parts Name

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
