Epson EB-X51 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 66 Revision A
3.1.4 Tools
The following table indicates the tools recommended for use for disassembly,
reassembly and adjustment.
3.1.4.1 Tool List
*1: q.s.: Sufficient quantity
*2: Usable item = “Grease G-78 (AQUADRY W-0082)”
3.1.4.2 Recommended Tool List
Tool Name Qt. Availability Application
Phillips screwdriver No. 00
(8 cm)
1

Disassembling the Focus Ring
and the zoom ring.
Phillips screwdriver No. 1
(10 cm)
1

Disassembling the outer cases
and inner components.
Phillips screwdriver No. 2
(10 cm)
1

Disassembling the outer cases
and inner components.
Hexagonal box screwdriver
(5 mm)
1

Removing the computer
interface
Flat-head precision screwdriver 1 Disassembling the Front Foot
Gloves 1

Anti-static wrist band 1

Be sure to wear them when
handling circuit boards or
Optical Engine.
Tweezers 1

Polyimide tape q.s.*
1

Securing cables.
Use commercially available
Polyimide tape generally called
“KAPTON
®
TAPE”.
Brush 1

Cleaning away dust.
Vacuum cleaner 1

Cleaning away dust.
Lens cleaner
(nonwoven cloth)
q.s.*
1

Cleaning the projection lens.
Lubricant*
2
q.s.*
1
Lubricating the shutter and its
frame.
Projection screen 1

To project images on.
Genuine power cable 1

Genuine remote controller 1

Insulation ohmmeter for
insulation resistance test
1

Rating: 500 V/100 MW
Multi meter 1

Ground continuity check
Air compressor or hand blower 1

To remove dusts from optical
parts and air filter.
Host computer 1

To output audio and video data
to the projector (To check the
component video input).
To control service tools
PC cable 1

Video equipment 1

To output audio and video data
to the projector (To check the
HDMI input).
Audio and Video cables
(HDMI/Composite/USB, and
each audio)
1 each

Multi tester 1

To measure resistance values
and voltages (AC/DC).
RS-232C cable 1

For writing DR data
USB memory or USB cable 1

For USB Updater.
IPS tool 1
See " 3.5.10 Service tool list
(p150)".
CAT 1
Intra-mart 1
RESCUE 1
USB firmware for updater 1
EasyMP Network firmware for
updater
1
Microsoft .Net Framework 3.5
or later
1
USB COM Driver 1
Tool Name Qt. Availability Application
Screwdriver magnetizer 1

To prevent the screw from
falling into the projector
Tool Name Qt. Availability Application

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
