Epson EB-X51 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 15 Revision A
I/O
Video input
Analog
D-sub 15pin 2 (Blue molding)
RCA 1 (Yellow)
DigitalHDMI1122222
Video output Analog D-sub 15pin 1
Audio
Input
RCA (L/R) 1
Stereo mini 2
OutputStereo mini1111112
Mic Input Stereo mini — — — 1 1 1 1
I/O
USB
Type A —111111
Type B 1
RS232C D-sub 9pin 1 (for servicing only)
Network
Cable LANRJ45 —111111
Wireless LAN
USB TypeA
(ELPAP11)
— 1 1 Optional Optional Optional 1
I/O
Wireless
connection
Screen Mirroring —
Operating Temperature
Temperature
5°C to 40°C [41°F to 104°F] (Elevation 0 to 2,286 m)
5°C to 35°C [41°F to 95°F] (Elevation 2,287 m or more)
Humidity 20% - 80% humidity
Operating Altitude
Normal 0 m to 3,048 m <0 ft to 10000 ft>
High altitude mode 1500 m <4921 ft> or more
Start-up period Less than 6 seconds
Warm-up period 30 seconds
Cool-down period Instant off
Power on was possible/impossible 100 - 240 V AC +/- 10%, 50/60 Hz
Model
EB-E20 EB-X49 EB-W49 EB-972 EB-982W EB-118 PL 119W
Item

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
