Epson EB-X51 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 168 Revision A
M-CUSHION H1W3L29 M-CUSHION,SHIELD;H1W3L29;PH
M-CUSHION H1W3L39 M-CUSHION,SHIELD;H1W3L39;PH
M-CUSHION H1W3L54 M-CUSHION,SHIELD;H1W3L54;PH
M-CUSHION H1W4L19 M-CUSHION,SHIELD;H1W4L19
M-CUSHION H1W10L17 M-CUSHION,SHIELD;H1W10L17;PH
WFD Shield Plate SHIELD PLATE,WFD;K;PH
FFC 30P FFC,SHIELD,30P-H838
FFC WFD-MA FFC,WFD-MA;22;H824
FFC WFD-WRF FFC,SHIELD,WFD-WRF;20;H814
WRF Holder HOLDER,WRF;K;PH
P3dash Module P3dash module
Upper Case
CASE,UPPER;H971-WH;PH
CASE,UPPER;KB-WH-J;PH
CASE,UPPER;KB-WH-E;PH
CASE,UPPER;KAL-WH-E;PH
CASE,UPPER;KAH-WH-E4;PH
CASE,UPPER;KAH-WH-E3;PH
CASE,UPPER;V-WH-E;PH
CASE,UPPER;V-WH-J;PH
CASE,UPPER;KAH-WH-E;PH
CASE,UPPER;KAH-BK-E;PH
CASE,UPPER;H978-WH-J;PH
CASE,UPPER;H978-WH;PH
CASE,UPPER;V-BK-E4;PH
CASE,UPPER;V-WH-J1;PH
CASE,UPPER;V-WH-E1;PH
CASE,UPPER;KAH-WH-E1;PH
Upper Cushion A
CUSHION,UPPER;A
CUSHION,PROLENS,A
Upper Cushion A-H722 CUSHION,UPPER;A-H722;PH
Name used in this manual SPI Parts Name
Upper Cushion B
CUSHION,UPPER;B,PH
CUSHION CASE UPPER;A
CUSHION,UPPER;B,PH
Sheet Upper A SHEET,UPPER;A-H850;PH
Sheet Lid Lamp SHEET,LID LAMP;H850;PH
Sheet Upper H854 SHEET,UPPER;H854;PH
Upper Case
COVER,CASE UPPER;PH
COVER,CASE UPPER;V;PH;2
Lid Lamp Switch SWITCH,LID LAMP;PH;2
H Key Assy H KEY ASSY;H972;PH;AS
LED Lens LENS,LED;A;PH
SW Button
BUTTON,SW;H971;PH
BUTTON,SW;a-WH;PH
BUTTON,SW;a-BK;PH
Power Button
BUTTON,POWER;AW
BUTTON,POWER;AB
SW Cable CABLE,SW; Au;PH;2
SW Board
PCB ASSY;H971SW-MP;PH
PCB ASSY;H981SW-MP;PH
PCB ASSY;H972SW-MP;PH
PCB ASSY;H980SW-MP;PH
Front Case
CASE UNIT,FRONT;H976;PH
CASE,FRONT;KH1a-WH;PH
CASE UNIT,FRONT;H974-WH;PH
CASE UNIT,FRONT;H974-SV;PH
CASE UNIT,FRONT;H978a;PH
CASE UNIT,FRONT;H980;PH
Shutter frame
FRAME,SHUTTER;KL;PH
FRAME,SHUTTER;KH;PH
FRAME,SHUTTER;V;PH
FRAME,SHUTTER;KH1;PH
Switch Cable H721-A CABLE,SWITCH-H721-A;PH;2
Name used in this manual SPI Parts Name

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
