Epson EB-X51 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 17 Revision A
 EB-FH06/FH52/992F, EH-TW740/TW750
Model
EB-FH06 EB-FH52 EB-992F EH-TW740 EH-TW750
Item
Specific
ation
of main
part
LCD
Size 0.61 inch (C2fine)
Pixel number 2,073,600 pixels (1920 x 1080) x 3
Native resolution Full HD
Aspect ratio 16:9
Projection Lens
Focus Type Manual
Zoom
Type Manual Manual Manual Digital Manual
Ratio 1-1.2 1-1.6 1-1.6 1-1.35 1-1.2
Lamp
Type UHE
Power consumption 210W 230W 230W 210W 210W
Life
Normal 6,000 hours 5,500 hours 6,500 hours 6,000 hours 6,000 hours
Medium — — 10,000 hours — —
Eco 12,000 hours 12,000 hours 17,000 hours 12,000 hours 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,500lm 4,000lm 4,000lm 3,300lm 3,400lm
Medium mode — — 3,400lm — —
Eco mode 2,300lm 2,400lm 2,400lm 2,200lm 2,200lm
Sound output Monaural: 2W x 1
Monaural: 16W x 1 Monaural: 16W x 1 Monaural: 2W x 1 Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding) 1 (Blue molding) 2 (Blue molding) — 1 (Blue molding)
RCA 1 (Yellow) 1 (Yellow) 1 (Yellow) — 1 (Yellow)
DigitalHDMI2 2212
Video output Analog D-sub 15pin — — 1 — —
Audio
Input
RCA (L/R)111—1
Stereo mini — — 2 — —
Output Stereo mini — — 1 1 1
Mic Input Stereo mini — — 1 — —

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
